    OEM OB Obstetric Ultrasound Equipment LCD Display TGC Control

    Ask Lasest Price
    Brand Name : OEM/ODM/Xianfeng
    Model Number : SP1
    Certification : CE\IOS\FDA
    Price : USD 320-360 / per set
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1000PCS Per Month
    Delivery Time : 5-8days
    • Product Details
    • Company Profile

    OEM OB Obstetric Ultrasound Equipment LCD Display TGC Control

    Full Digital Human Used Portable Ultrasound Machines 12.1 Inch LED

    Human Digital Ultrasound Machines Black And White BB BM 12.1in LED Screen 0

    Features:
    1. Mass memory , cine loop and permanent storage.
    2. Radium Caved buttons and Silicon backlit buttons to be chosen;
    3. Intelligent fluorescence trackball.
    4. 8-segment TGC control. Overall Gain control
    5. 2 USB ports , Upgraded and expandable printer function;
    6. 2probe connectors. Probe automatic identfication;
    7. 2SVGA video outputs and 21 PAL video outputs offer connection to video image recorder and image workstation. etc.
    8. Report page is generated automatically.
    9. According to the user's pattern style preference, the parameter will be set up automatically and saved ,Boot default this
    parameter. This default of parameter can aslo be modified in the menue.

    ModelXF30A(XF50) Note book ultrasound Scanner
    Display Modes3.5MHz/R60 convex array probe: B,B/B,4B,B+M,M
    6.5MHz/R13 Dimpling array probe: B
    7.5 MHz/L40 Line array probe: B
    Image Mutiplying Factor

    3.5MHz/R60 convex array probe:

    x0.8, x1.0, x1.2, x1.5,x1 .8, x2.0( 6modes)

    x0.8, x2.0 (display penetration depth)

    6.5MHz/R13 Dimpling array probe: x0.8, x1.0, x1.2, x1.5 (4 modes)
    7.5MHz/L40 Line array probe: x0.8, x1.0, x1.2, x1.5 (4 modes)
    E-zoommagnify 2 times of real time image
    Dynamic Range0~120dB ajustable
    Focus Position1,2,3 and 4-segments dynamic electron focusing
    Image Processingγcorrection, frame correlation,point correlation, line correlation, digital filtering, digital edge enhancement and pseudo color processing, etc.
    According to the user’s pattern style preference, the parameter will be set up automatically and saved ,Boot default this parameter. This default of parameter can aslo be modified in the menue.
    Frequency Conversion2.5MHz/3.0MHz/3.5MHz/4.0MHz/5.0MHz five periods of frequency conversion
    frequency range applies 5.5 MHz/6.0 MHz/6.5 MHz/7.0 MHz/7.5MHz can match high frequency probe
    Measuring FunctionDistance,circumference/area (method of ellipse, method of loci), volume, heart rate, gestational weeks (BPD,GS,CRL,FL,HL,OFD,TTD,AC), expected date of confinement and fetus weight, etc.
    Annotation Functionhospital name, patient’s name, age and gender 64 body marks (with probe’s position);
    Full-screen character annotation; Real-time clock display
